LUXALON® Linear Ceilings

No matter your style, our linear ceilings have the looks you love. Whatever your project’s needs, our linear ceilings give you the freedom to think inside or outside the box. Our ceiling systems highlight versatility, allowing a variety of visual effects, including radial and diagonal patterns and curves.

DESIGN FLEXIBILITY

Luxalon® Linear ceilings provide interesting possibilities for directional room designing. Our ceiling systems highlight versatility, allowing a variety of visual effects, including radial and diagonal patterns, finishes and curves. Choose from over 40 available colours and mix and match different sizes and heights to create the perfect look for your project.

DURABILITY

Luxalon® Linear ceilings are manufactured from durable roll formed aluminium coil, 0.35 mm, 0.5 mm or 0.6 mm finished with a polyester paint to provide a long, low maintenance life. The coating is stove enamelled in a continuous coil coating process ensuring uniform coating thickness and absolute adhesion. For exterior applications aluminium panels with Luxacote® finish are available.





LUXALON® Wide Panel

Wide Panel Ceilings enables the architect to design a closed ceiling with high performance aluminium or steel materials. In order to give maximum freedom in design there is a wide choice in panels with soft edges for a monolithic ceiling appearance or panels with square or bevelled edges which results in a smooth ceiling with a narrow butt joint.

DESIGN FLEXIBILITY

The robust wide panel appearance provides interesting possibilities for spatial room designing. The ceiling panels show a straight L-joint, neat V-joint or a 10 mm wide recessed joint. The panels can be installed as Clip-in, Lay-on, Carrier or C-grid system. The 300 mm wide panels are available up to 6 m length. A range of colours and finishes is standard available and special colours upon request.

DURABILITY

Wide panel ceilings are manufactured from durable roll formed aluminium (0.7 mm) or steel (0.6 mm) coil, finished with a polyester paint to provide a long, low maintenance life. The coating is stove enameled in a continuous coil coating process ensuring uniform coating thickness and absolute adhesion. For exterior applications aluminium panels with Luxacote® finish are available.





LUXALON® Magnagrid

Luxalon® Magnagrid is a highly versatile open cell interior ceiling system which is assembled to provide a wide range of modular cell sizes in a variety of colours and finishes.

DESIGN FLEXIBILITY

  • A range of modular cell sizes provides a visually appealing and versatile slim-line cell framing system.
  • Made to measure: standard and customised panel lengths result in minimal installation time and economy of product due to minimal wastage
  • A wide range of colours and finishes available

ACOUSTIC PERFORMANCE

  • Adding absorbant materials to the rear of the ceiling or within the void space can be effective in controlling noise

DURABILITY

  • Hunter Douglas Coil Coated aluminium interlocking blades and components ensure a long life, requiring minimal maintenance
  • Made to measure: standard and customised panel lengths result in minimal installation time and economy of product due to minimal wastage

EASE OF INSTALLATION

  • Time on site is minimised and wet trades are eliminated, reducing disruption to other trades
  • Lightweight which means it is both easy to handle onsite and applies only a light weight to the building structure
  • Integration of services eg lighting, air conditioning and other services can be integrated into this building system
  • Easy plenum access: panels can be simply removed and replaced, allowing full access to above ceiling system

ENVIRONMENTAL SUSTAINABILITY

  • Materials are recyclable and made up of recycled content



Magnagrid - Luxalon Magnagrid Product of Hunter Douglas Architectural Products
Hunter Douglas Luxalon® Magnagrid Supplied in Australia by Concept Metal Ceilings

SCREEN CEILINGS

The Luxalon® Screen Ceiling is ideal for applications where the design criteria is to visually reduce the room height while retaining original room volume. The Luxalon® screen ceiling excels at diffusing daylight or artificial light entering from above. At a minimum angle of approximately 45 degrees, the ceiling has a closed appearance

The V100/ V200 screen ceiling is suitable for those building sectors where a light weight and open ceiling is required. These include corporate, transport (airports, metro, bus & train stations), retail, leisure, public space and hospitality environments.

DESIGN FLEXIBILITY

Luxalon® V100/ V200 screen ceilings enable architects to design an open ceiling with high-performance aluminium.

  • Variety of panel heights, modules and systems these ceilings offer maximum freedom in design
  • Spacious appearance ideal for interior designs where open, light constructions are desired.
  • Systems are available as fixed carrier
  • 2 different profile types (100/200mm) and three different modules (100/150/200mm) are available as standard or special.

EASE OF INSTALLATION

  • Vertically installed panels in 100, 150 or 200mm module
  • The panels clip easily to the carrier.
  • Fixing clips fitted on the carriers between the panels provide a secure locking of the panels and make the system suitable for exterior applications (only V100)
  • Panels can be supplied in any length up to 6000 mm (as standard)
  • If required, panels and fixing clips are easily demountable by hand, which allows full access to services and equipment in plenum

FINISH

  • Available in a standard Luxalon Colour range. For External applications panels with Luxacoat® finish are available.
Screen Ceiling - Open Ceiling - Hunter Douglas Architectural Products - Supplied in Australia and New Zealand by Concept Metal Ceilings
Screen Ceiling – Open Ceiling – Hunter Douglas Architectural Products – Supplied in Australia and New Zealand by Concept Metal Ceilings

HEARTFELT® Modular Felt Ceiling System

Heartfelt® is an innovative, patented product that turns every ceiling into a visual and acoustic playground.

Inspired by felt as an intriguing material for clothing, furniture, and fashion accessories, with Heartfelt® ceiling system, Hunter Douglas is providing Architects, installers and building owners with an advanced system that allows them to create the right ambiance and to precisely manage the acoustics of every space.

DESIGN FLEXIBILITY

The felt panels are available in various heights as well as five different grey tones and five earth tones, and can be easily clipped to the carriers at varying distances.

In addition to the 55-mm panels, the grey tones are also available in 80 and 105-mm panels. The modular system along with a wide range of options in terms of colour and height offer designers a host of design options and variations.

HeartFelt® is suitable for most building sectors: Corporate, Retail, Leisure, Public Space, Hospitality, Healthcare, Education or Residential

SUSTAINABLE

The linear felt ceiling panels that comprise HeartFelt® are made of non-woven, thermoformed PES fibres. No finishing coat is applied to the panels, making the panels 100% recyclable. The carriers (aluminium) and hangers (galvanised steel) are 100% recyclable.

CHARACTERISTICS

Great Acoustic Performance

100% Recyclable or Easily Reusable

Easy Installation and Low risk for damages

Download HeartFelt®Brochure

Heartfelt - Textile Linear Acoustic Ceiling by Hunter Douglas
Heartfelt® M50 Light Grey

LUXALON® Custom Metal Tiles

No matter your style, our ceilings have the looks you love. Whatever your project’s needs, our Tile Ceilings give you the freedom to think inside or outside the box.

DESIGN FLEXIBILITY

Luxalon® Tile Ceiling systems from Hunter Douglas offer the combination of style and functionality for which we are known. These systems are available in different installation concepts.

Lay-On and Lay-In Tiles provide easy access and are ideal for situations where regular maintenance or service is required on installations in the plenum. Clip-In Tiles are available in a wide variety of pre-defined square and rectangular module sizes that are common used in ceiling design. For frequent accessibility, swing down Clip-In Tiles can be included in the ceiling design.

LONG LASTING, LOW MAINTENANCE

Luxalon® Tile Ceiling systems are manufactured from durable aluminium or steel. Finished with a powder coating or produced from durable coil coated material, these ceilings will last longer and require less maintenance.

PERFECTLY PERFORATED ACOUSTICS

Perforated tiles improve acoustical performance as well as creating aesthetic effects. Luxalon® perforated Tiles come with a special sound-absorbing non-woven tissue glued into the panel, further enhancing acoustical performance.

LUXALON® Sun Louvre

A versatile advanced design, providing systems for open wall cladding, sun louvres and ventilation screens.

The panels have the same profile and are available in tow dimensions: 70S with a height of 70mm and 132S, being 132mm high.

These functional, yet aesthetically pleasing profiles can be installed at any module depending on the requirements of each specific application.

Special Luxalon® mounting brackets are provided which ensure a secure installation of the panels. When installed as a vertical Sun Louvre, this system offers an effective and simple way to protect a building and its occupants against direct solar radiation.

The interception of direct sunrays onto the window glass prevents excessive heat through solar gain. Intensive sunlight is reduced and the rooms are more evenly illuminated by diffused light. The open construction does now obstruct the view or the natural airflow and pockets of hot air will not build up along the facade.

In projects where air conditioning is incorporated the application of Luxalon® Sun Louvres will reduce the operating costs. This Luxalon® louvre system can also be applied for ventilation screens and offers an effective solution for creative installation such as open facade constructions in, for example, multi storey car parks.

Our Other Products

  • LUXALON® Multipanel series
  • LUXALON® Magnagrid Cell
  • LUXALON® Screen

Download brochures

Concept Metal Ceilings Pty Ltd is the distributer for Hunter Douglas Luxalon® Architectural Products – Ceilings, Facades and Sun Control, in Australia, New Zealand and the Pacific Island Nations
